RANGER 451i

Name: RANGER 451i
Brand: MOBITECH INDUSTRIES LLP.
Price: 149999.0 INR
Availability: InStock

149999.0 INR/Number

Get a Price/Quote

Product Details:

Suitable For Heavy Fabrication, Construction, Structural Welding
Power 22.8 kVA
Dimension (L*W*H) 630mm x 310mm x 590mm
Capacity 450 Amps Output
Ambient Temperature -10C to +40C
Product Type Inverter ARC Welding Machine
Material Heavy Duty Metal Body
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

RANGER 451i Price And Quantity

Price 149999.0 INR/Number
Minimum Order Quantity 1 Number

Power Factor 0.93
Color Red and Black
Hot Start Function Yes
Technology IGBT Module Based
Mounting Type Portable with Handle and Wheels
No-Load Voltage 70V max
Electrode Diameter Range Up to 6.0 mm
Duty Cycle 60% at 450A
Phase Requirement 3 Phase Only
Display Digital Meter For Current
Protection Class IP21S
Anti-Stick Function Yes
Arc Force Adjustment Available
Efficiency 85%
Cooling Type Fan Cooled System
Insulation Class Class H

RANGER 451i Product Specifications

Product Type Inverter ARC Welding Machine
Input Voltage 415V AC, 3 Phase
Suitable For Heavy Fabrication, Construction, Structural Welding
Charger Type Three Phase Input, Welding Rectifier
Output Voltage 60V DC
Voltage Range 340V - 460V
Material Heavy Duty Metal Body
Ambient Temperature -10C to +40C
Socket Type Industrial Socket Compatible
Rated Frequency 50/60 Hz
Size Large, Portable With Wheels
Capacity 450 Amps Output
Weight Approx. 33.5 kg
Usage Industrial ARC Welding Application
Power 22.8 kVA
Dimension (L*W*H) 630mm x 310mm x 590mm

Power Factor 0.93
Color Red and Black
Hot Start Function Yes
Technology IGBT Module Based
Mounting Type Portable with Handle and Wheels
No-Load Voltage 70V max
Electrode Diameter Range Up to 6.0 mm
Duty Cycle 60% at 450A
Phase Requirement 3 Phase Only
Display Digital Meter For Current
Protection Class IP21S
Anti-Stick Function Yes
Arc Force Adjustment Available
Efficiency 85%
Cooling Type Fan Cooled System
Insulation Class Class H

RANGER 451i Trade Information

Supply Ability 500 Number Per Month
Delivery Time 7 Days

Product Description

No more low battery anxiety or battling for charging ports. Mobillas new Ranger 451i has got you covered. This efficient car charger is here to save the day and your battery on those long trips.

Features :

Powerful Dual Ports
Adaptive Charging
Universal Compatibility
Multilayer Protection
Compact Size
Durable Body

Superior Welding Performance for Heavy Industries

The RANGER 451i stands out in industrial environments, offering a high output of 450 amps and supporting electrodes up to 6.0 mm. Its sturdy design, efficient cooling, and advanced IGBT technology ensure consistent performance, even during long hours of fabrication or construction. With durable metal construction and a large, portable build, this machine is tailored for challenging welding applications.

Comprehensive Features for Enhanced Welding Control

Operators benefit from advanced features such as hot start, anti-stick, arc force adjustment, and a digital current meter. These allow for precise, flexible control during each weld, reducing electrode sticking and facilitating easy arc initiation. The IP21S protection class and Class H insulation increase safety, making the RANGER 451i reliable for continuous industrial use.

Portability Meets Durability

Despite its large size and 33.5 kg weight, the RANGER 451i is designed for mobility within industrial environments. It features a sturdy handle and wheels, ensuring that it can be easily transported around fabrication sites or large facilities. Its tough metal casing withstands harsh working conditions, offering long-lasting resilience.

FAQ's of RANGER 451i:

Q: How do I set up the RANGER 451i for use in an industrial welding application?

A: To set up the RANGER 451i, ensure a three-phase input supply of 415V AC is available. Plug the machine into an industrial-compatible socket, select the appropriate electrode (up to 6.0 mm), and adjust parameters using the digital current meter. The portable design with wheels allows easy movement to your desired location.

Q: What advantages does the IGBT module-based technology offer in the RANGER 451i?

A: The IGBT (Insulated Gate Bipolar Transistor) module ensures high efficiency (up to 85%), fast switching, and stable output. This technology improves power factor, reduces energy consumption, and enhances weld quality, making it ideal for demanding industrial applications.

Q: When is the hot start and anti-stick function beneficial to the user?

A: The hot start function is particularly valuable during electrode ignition, making arc striking smoother and reducing initial sticking. The anti-stick function prevents the electrode from adhering to the workpiece, making operations smoother and reducing downtime.

Q: Where is the RANGER 451i best utilized?

A: The RANGER 451i is engineered for heavy-duty sites such as fabrication workshops, industrial construction zones, and structural welding projects. Its rugged build and reliable performance make it suitable for applications across India requiring durable and powerful welding equipment.

Q: What process controls are available to the operator?

A: The operator has access to digital metering for precise current control, arc force adjustment for arc stability, and selectable hot start and anti-stick features for optimal arc performance. These features enable fine-tuning to match varying welding conditions and materials.

Q: How does the fan-cooled system benefit the RANGER 451i?

A: The integrated fan-cooled system maintains safe operating temperatures, enhancing both efficiency and longevity of the machine. Effective cooling allows for higher duty cycles and consistent output during prolonged industrial welding tasks.

Q: What are the benefits of the RANGER 451i's portability and mounting design?

A: Equipped with durable wheels and a carry handle, the RANGER 451i can be easily relocated within large industrial sites. This mobility, combined with its robust construction, ensures flexible deployment wherever heavy fabrication or structural welding is required.
